WAC Limited - PS-24DC-U3X96R-BT - Gemini - 3x96W 24VDC Remote Power Supply-1.75 Inch Tall and 4.13 Inch Wide

This class 2, UL & cUL listed enclosed electronic transformer is used to power Gemini Tape Light by WAC Lighting. Class 2 transformers are intrinsically safer transformers because they are compartmentalized to allow no greater than 5 amps of current to be drawn on each compartment. Enclosure cover is easy to remove. Transformer has knockouts with clips for line voltage wiring. Secondary low votlage wiring for class 2 transformers do not require conduit sheathed cable or clamp wiring techniques. This transformer has a low minimum load requirement of 1W to allow the use of LED products. May be dimmed using an electronic low voltage dimmer. Includes a 72in lead wire for Gemini, longer lead wires (T24-BS-EX2) are sold separately.

• Fully enclosed remote power supply with knockouts and clips for line voltage wiring. Soft start, short and overload circuit protection features. For use with WAC Lighting Basics & Gemini Tape Light systems.
• 1W Minimum load to support low load LED systems. Intrinsically safe, Class 2 transformers permit no greater than a 5 amp current to be drawn. Includes a 72in lead wire for Basics & Gemini, longer lead wires (T24-BS-EX2) are sold separately.
• Secondary wiring for Class 2 transformers does not require conduit sheathed cable or clamp wiring techniques. Suggested low voltage wire type (Sold separately): 14 - 18 guage stranded or solid. Non-metallic sheathed cable may be used for secondary wiring in walls and ceilings.
• Input Voltage: 120-277VAC, Output Voltage: 24VDC. Available in 60W, 96W, and 3x96W options.
• Smooth and continuous dimming with 0-10V,ELV, and TRIAC dimmers. Dimmers should always be installed on the primary side of the transformer.
• Standards: UL & cUL Listed IP20 for Damp Locations
